    Smart Tempered Glass Remote On/Off Switch with LED Indicator

    Ask Lasest Price
    Brand Name : UBARO-Wireless Remote Control Main Switch
    Model Number : ZS-WW1Y-YK
    Certification : CE Rohs FCC
    Price : Price negotiable
    Delivery Time : 10-15 Work days
    Payment Terms : TT
    Supply Ability : 5000pcs
    • Product Details
    • Company Profile

    Smart Tempered Glass Remote On/Off Switch with LED Indicator

    Product Description:

    1,Brand Name: UBARO
    2,Button:1 gang,2gang,3gang for you choose
    3,Color: Black, White, Golden
    4,Size: 8.6*8.6*3.5cm / 3.4*3.4*1.4" (L*W*H)
    5,Current: 10A
    6,Watt:5-300W/gang
    7,Working Voltage: 170V-240 V AC
    8,Working Temperature: -20 ℃~+70℃
    9,Relative Humidity: 10% ~ 90%
    10,Mechanical Life: 100000 Times
    11,Certification: CE,CCC ,ROHS
    12,Warranty: 1 year
    13,Delivery time: <3 days Received your order
    14,Gross weight:0.15kg/5.25oz Net weight: 0.14kg / 4.9oz
    15,Package dimensions:9.0*9.0x4.0cm/3.5x3.5x1.55(L*W*H)

    Features:

    There is a method to match a RF433 switch with a touch remote control, which can be found in the manual for detailed instructions. To initiate the process, wait for a beep sound before pressing and holding the switch button for 3 seconds. Then press the remote control to learn the signal. The switch will beep when opened or closed.

    When the "on" button is pressed, the switch will emit two beeps. On the other hand, when the "off" button is pressed, the switch will emit three beeps. Finally, when you want to "remove" the signal, the switch will beep four times.

    For any further assistance, users can contact the UBARO service mailbox at pingan@ubaro-switch.com.


    Technical Parameters:


    UBARO Remote Switch Pairing and Battery Selection

    If you need to pair your UBARO remote switch with the remote control finger, there are a few simple steps you can follow:

    1. Press and hold the main switch button for 5 seconds.
    2. When you hear a beep, release your finger.
    3. Press the button on the remote control to turn the switch on and off.

    If you need to clear the paired data from your UBARO remote switch, you can also follow these simple steps:

    1. Press and hold the main switch button.
    2. When you hear four beeps - di, di, di - release your finger.
    3. All paired data will be cleared.

    To ensure your UBARO remote switch is running on the correct battery, select a 23A 12V alkaline battery. This will help to keep your switch running smoothly, without interruptions or delays.

    For any further assistance or queries, please contact the UBARO service mailbox at Alex@ubaro-switch.com.


    Switch Installation
    • The power needs to be turned off during installation.
    • Please connect the "L" position to FireWire correctly.
    • Located at the "L1", "L2" and "L3" positions respectively to control the light bulb.
    • The cover can be opened to complete the final process.
    • The figure below is the schematic diagram of the capacitor installation:

    The installed load bulbs are halogen lamps, led bulbs, high-voltage strips, smart led bulbs or bulbs less than 5W, all need to install this yellow safety capacitor, and the capacitors are connected in parallel to control the live and neutral wires.

    Contact UBARO service mailbox at pingan@ubaro-switch.com for any inquiries.


    Support and Services:


    Our Wireless Remote Switch product comes with a comprehensive technical support and service package to ensure optimal performance and customer satisfaction. Our team of experts is available to assist with any technical issues or questions that may arise during installation or use of the product.

    Our technical support services include:

    • Assistance with initial product setup and installation
    • Troubleshooting and problem-solving support
    • Guidance on product features and functionality
    • Software and firmware updates and upgrades

    In addition to our technical support services, we also offer a range of maintenance and repair services to keep your Wireless Remote Switch product in top condition. Our services include:

    • Regular maintenance checks and tune-ups
    • Repair services for any damage or malfunctions
    • Replacement parts and accessories

    With our comprehensive technical support and service package, you can trust that your Wireless Remote Switch product will provide reliable and efficient performance for years to come.


    Packing and Shipping:


    The wireless remote switch will be packaged securely in a cardboard box to prevent any damage during shipping. The box will also include a user manual and batteries for the remote control.

    Shipping:

    The wireless remote switch will be shipped via a trusted courier service within 1-2 business days after the order is placed. The estimated delivery time is 5-7 business days, but may vary depending on the shipping location. A tracking number will be provided to the customer once the product has shipped.
